Taizhou Kayond Machinery Co., Ltd
| Nguồn gốc: | Jiangsu, Trung Quốc |
|---|---|
| Hàng hiệu: | KAD |
| Số lượng đặt hàng tối thiểu: | 1 |
| Giá bán: | $1,285-1,680 |
| Độ dài nĩa: | 1070mm | Chiều rộng của nĩa: | 550/680mm |
|---|---|---|---|
| Trung tâm tải: | 500mm | Tải trọng: | 1500kg |
| Điện áp pin: | 24V | Dung lượng pin: | 80Ah |
| Loại pin: | Axit chì | Chiều cao nâng tối thiểu: | 2080mm |
| Kích thước tổng thể: | 1770x850x2080mm | Cân nặng: | 500kg |
| tốc độ lái xe: | 5,0mm/s | Tốc độ nâng: | 140/135mm/s |
| Tốc độ giảm dần: | 150/155mm/s | Động cơ lái: | DC/0,75kW |
| Động cơ nâng: | DC/2.2kW | ||
| Làm nổi bật: | 1600kg electric pallet stacker,3000mm lift pallet stacker,KAD electric pallet stacker |
||
| Attribute | Value |
|---|---|
| Condition | New |
| Fork Length | 1070mm/customized |
| Fork Width | 550/680mm/customized |
| Applicable Industries | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising |
| Terrain Adaptability | Indoor Flooring, Outdoor Pavement, other |
| Load Center | 500 mm |
| Load weight | 1500KG |
| Battery | 24V/80Ah |
| Battery type | Lead acid battery |
| Power Source | DC MOTOR |
| Warranty | 1 Year |
| Min. Lifting Height | 2080mm |
| Overall Dimensions | 1770(L)*850(w)*2080(h) |
| Weight (KG) | 500 kg |
| Model | CDDW10 | CDDW15 |
|---|---|---|
| Drive system | Battery | |
| Driving mode | Walkie | |
| Load Capacity (KG) | 1000 | 1500 |
| Load Center (MM) | 500 | |
| Lifting Height (MM) | 1600/2000 | 2500/3000 |
| Driving Speed (Empty/Full Load) (MM/S) | 5.0/5.0 | |
| Lifting Speed (Empty/Full Load) (MM/S) | 140/135 | |
| Battery Capacity (V/Ah) | 24/80Ah | |
Control Handle: Domestic famous control handle with functional buttons for UP/DOWN, FORWARD/BACKWARD control. Features Curtis brand accelerator for safe operation.
